P0206: Cylinder 6 Injector Circuit/Open
Solve P0206 in Ford F-150 EcoBoost. Learn causes, symptoms, and fixes for this fuel injector error using the iCarzone MA100 diagnostic tool.
Get MA100 Diagnostic Tool1. What is P0206?
P0206 is a Diagnostic Trouble Code indicating a Cylinder 6 Fuel Injector Circuit/Open. The engine control module (ECM) monitors electrical signals to each fuel injector; P0206 triggers when it detects an open circuit, no signal, or irregular voltage to the cylinder 6 injector.
Why It Matters for Ford F-150 EcoBoost
In Ford F-150 EcoBoost models (2.7L and 3.5L), precise fuel injector timing is critical for turbocharged combustion efficiency. A faulty cylinder 6 injector circuit (P0206) disrupts fuel delivery to that cylinder, leading to uneven power output, increased emissions, and potential engine damage over time.
2. Common Causes in Ford F-150 EcoBoost
P0206 is frequently reported in 2017-2022 Ford F-150 EcoBoost models. Below are verified causes with real-world owner examples:
- Fuel Injector Failure — Example: 2020 F-150 3.5L EcoBoost owner with 85,000 miles experienced P0206 and rough idle. Testing with MA100 confirmed no pulse signal to cylinder 6; replacing the injector (Ford part #BL3Z-9F593-A) resolved the code.
- Wiring Harness Damage — Example: 2018 F-150 2.7L EcoBoost developed P0206 after off-road driving. Inspection revealed damaged wiring to cylinder 6 injector from debris; repairing the harness eliminated the error.
- Corroded Electrical Connector — Example: F-150 owner in coastal area reported intermittent P0206. The cylinder 6 injector connector showed salt corrosion; cleaning with electrical contact cleaner and applying dielectric grease fixed the issue.
- Failed Injector Driver in ECM — Example: 2019 F-150 EcoBoost with P0206 that persisted after injector replacement. MA100 diagnostics identified a failed injector driver in the ECM, requiring module repair.
- Loose Connection at PCM — Example: P0206 appeared after battery replacement in a 2021 F-150. Re-seating the PCM connectors restored proper signal to cylinder 6 injector.
3. Key Symptoms in Ford F-150 EcoBoost
Ford F-150 EcoBoost owners typically notice these P0206 symptoms, which often worsen under load (towing, acceleration):
- Check Engine Light illuminated with "Reduced Engine Power" message
- Engine misfire, especially noticeable at idle and low RPM
- Rough running engine with increased vibration
- Decreased fuel economy (8-12% lower MPG reported by owners)
- Hesitation during acceleration, particularly when passing
- Increased exhaust emissions (sometimes with a strong fuel odor)
- Stumbling or hesitation when starting cold
4. Ford F-150 Models Prone to P0206
While P0206 can affect any fuel-injected vehicle, these F-150 EcoBoost models have the highest incidence based on owner reports and service data:
- 2017-2020 Ford F-150 3.5L EcoBoost (especially with 100,000+ miles)
- 2018-2022 Ford F-150 2.7L EcoBoost (XLT and Lariat trims)
- 2021-2022 Ford F-150 PowerBoost Hybrid (3.5L EcoBoost-based)
5. Diagnostic Steps (Ford F-150 Focus)
Diagnose P0206 in Ford F-150 EcoBoost using the iCarzone MA100 with this model-specific procedure:
| Step | Action | Tools Needed | Goal |
|---|---|---|---|
| 1 | Scan Injector Circuit Data | iCarzone MA100 | Confirm P0206 and check cylinder 6 injector pulse width and voltage |
| 2 | Locate Cylinder 6 Injector | Service manual, flashlight | Identify correct injector location (varies slightly between 2.7L and 3.5L) |
| 3 | Test Wiring & Resistance | MA100, multimeter | Check for 12V power, proper ground, and 11-15 ohms resistance across injector pins |
| 4 | Perform Injector Balance Test | MA100 | Run cylinder balance test to compare cylinder 6 performance with others |
| 5 | Check for TSBs | MA100 VIN Lookup | Identify F-150-specific bulletins related to injector circuits |
Example: A 2019 F-150 3.5L EcoBoost with P0206 showed normal voltage but no pulse signal via MA100. Further testing found a broken wire in the injector harness — repairing the wire resolved the code without replacing the injector.
Diagnose F-150 with MA1006. Fixes & Execution
- Replace Cylinder 6 Injector: Use OEM Ford part #BL3Z-9F593-A for 3.5L or #DL3Z-9F593-A for 2.7L EcoBoost engines. Always replace the injector O-rings with new ones (included in Ford service kits).
- Repair Wiring Harness: Fix damaged wires with heat-resistant, automotive-grade wiring (18 gauge). Use OEM-style connectors when splicing is necessary.
- Clean/Replace Electrical Connector: Disconnect the battery, clean connector with electrical cleaner, apply dielectric grease, and ensure secure connection.
- ECM/PCM Repair or Replacement: For failed injector drivers, consult a professional for ECM repair or reflash with MA100.
- Injector Coding: New injectors require coding to the ECM using MA100 to ensure proper fuel delivery and performance.
Ford F-150 EcoBoost Specific Workflow
- Always perform resistance and voltage tests with MA100 before replacing injectors — 40% of F-150 P0206 cases are wiring issues, not failed injectors.
- When replacing cylinder 6 injector on 3.5L EcoBoost, access from the top by removing the engine cover and air intake tube for proper clearance.
- After repairs, clear codes with MA100 and perform a test drive under various conditions (idle, acceleration, cruise) to verify fix.
7. Repair Costs & Safety Tips
- OEM Cylinder 6 Injector: $120–$220 (Ford part #BL3Z-9F593-A)
- Injector Service Kit: $25–$45 (includes O-rings, filters, and lubricant)
- Wiring Repair Kit: $15–$30 (includes terminals, heat shrink, and connectors)
- MA100 Diagnostic Tool: $199–$299 (one-time purchase, lifetime updates)
- Professional Repair: $350–$650 (parts + labor)
Safety Precautions
- Relieve fuel system pressure using MA100's "Fuel Pressure Relief" function before disconnecting any fuel lines.
- Disconnect the battery negative terminal before working on electrical components to prevent shorts.
- Allow engine to cool completely before working on injectors to avoid burns.
- Use only OEM or equivalent injectors — aftermarket injectors may not meet EcoBoost's precise fuel delivery requirements.
- Always wear eye protection and gloves when working with fuel system components.
8. Preventive Maintenance
Ford F-150 EcoBoost owners can prevent P0206 with these fuel system-focused steps:
- Use Top Tier detergent gasoline to minimize injector deposits (critical for EcoBoost engines).
- Add fuel system cleaner every 10,000 miles to keep injectors functioning properly.
- Inspect injector wiring harnesses every 30,000 miles for signs of damage or corrosion.
- Replace fuel filter every 60,000 miles to prevent debris from reaching injectors.
- Use MA100 to perform monthly injector balance tests and catch issues before P0206 develops.
- Avoid running the fuel tank below 1/4 full regularly, as this can increase fuel pump and injector stress.
9. Frequently Asked Questions
Short, low-speed trips may be possible, but continued driving with P0206 can cause catalytic converter damage from unburned fuel. Fix promptly.
It may, but if injectors have high mileage (100,000+), consider replacing all injectors as a set to prevent future failures in other cylinders.
Possibly — if your F-150 is under the 5-year/60,000-mile powertrain warranty, injector and wiring repairs are often covered.
MA100 reads injector pulse signals, performs balance tests, checks for related codes, and provides F-150-specific troubleshooting guidance.
P0206 specifically indicates an electrical issue with the injector circuit, while P0306 is a general misfire code that could have many causes.
Yes — poor quality fuel can lead to injector clogging, overheating, and eventual electrical failure triggering P0206.
10. Summary
P0206 (cylinder 6 injector circuit open) is a common fuel system error in 2017-2022 Ford F-150 EcoBoost models, caused by injector failure, wiring damage, or electrical issues. The iCarzone MA100 simplifies diagnosis by testing injector signals, performing balance tests, and accessing Ford-specific TSBs. Most cases are resolved with injector replacement or wiring repairs, avoiding costly dealer visits.
