1. What is P0711?

P0711 is a Diagnostic Trouble Code indicating a Transmission Fluid Temperature Sensor Circuit Low Input. The transmission fluid temperature (TFT) sensor monitors the temperature of the transmission fluid—critical for adjusting shift points, torque converter lockup, and fluid pressure. P0711 triggers when the Engine Control Module (ECM) or Transmission Control Module (TCM) detects sensor voltage below the normal range (typically below 0.5 volts), signaling a potential sensor failure, wiring short, or fluid-related issue.

Why It Matters for Chevrolet Silverado 1500

For Silverado 1500 owners—especially those with 6-speed or 8-speed automatic transmissions—accurate TFT data is vital to prevent transmission damage. Without proper temperature readings, the TCM may default to "limp mode" (restricting speed and gear changes) to protect internal components. P0711 can also cause harsh shifting, reduced fuel efficiency, and accelerated wear on clutches and bands. UR800’s advanced transmission diagnostics help pinpoint whether the issue stems from the sensor, wiring, or TCM.

2. Common Causes in Chevrolet Silverado 1500

P0711 in Silverado 1500 typically involves issues with the TFT sensor circuit or related components. Common causes include:

• Failed Transmission Fluid Temperature Sensor — Internal electrical failure (common in 2014–2019 Silverados with 6L80 transmissions).
• Wiring or Connector Damage — Corroded pins, frayed wires, or short circuits in the sensor harness (vulnerable near the transmission pan).
• Low Transmission Fluid Level — Insufficient fluid preventing proper sensor contact (critical in 8-speed 8L90 transmissions).
• Contaminated Transmission Fluid — Sludge or debris coating the sensor (common in high-mileage trucks).
• TCM Software Glitch — Incorrect voltage reading interpretation (2020–2023 models may require calibration updates).
• Ground Circuit Issue — Poor electrical ground causing voltage irregularities.

3. Key Symptoms in Chevrolet Silverado 1500

Owners typically notice these P0711-related symptoms in their Silverado:

• Check Engine Light illuminated with P0711 (often paired with P0712 in severe cases)
• Harsh or delayed shifting, especially during cold starts
• Transmission "limp mode" activation (max speed limited to 40–50 mph)
• Inaccurate or fluctuating transmission temperature gauge
• Reduced fuel efficiency due to improper shift timing
• UR800 live data showing TFT sensor voltage below 0.5V

4. Silverado 1500 Models Prone to P0711

While P0711 can occur across model years, certain Silverado 1500 variants show higher incidence due to transmission design:

• 2014–2019 Silverado 1500 (6L80 transmission) — Sensor failure common at 80,000–120,000 miles.
• 2017–2023 Silverado 1500 (8L90 transmission) — Wiring harness chafing near the transmission case.
• High-output 6.2L V8 models — Increased transmission heat accelerates sensor wear.
• Fleet or work trucks — Frequent heavy loads strain transmission components, including sensors.

GM TSB 22-NA-062 addresses P0711 in 2020–2022 Silverados, recommending updated sensor connectors and TCM reflash.

5. Diagnostic Steps (Silverado 1500 Focus) with UR800

Use UR800 to isolate whether P0711 stems from a sensor, wiring, or fluid issue:

Case Example: A 2018 Silverado 1500 with 6L80 transmission showed P0711 and harsh shifting. UR800 live data revealed 0.3V sensor reading. Resistance test confirmed open circuit. Replacing the sensor (located in the transmission pan) restored normal voltage and resolved symptoms.

6. Fixes & Execution for Chevrolet Silverado 1500

Repair depends on UR800 test results—60% of P0711 cases require sensor or wiring fixes:

• Replace Transmission Fluid Temperature Sensor — - Drain transmission fluid and remove pan (6L80: 18 bolts; 8L90: 20 bolts) - Locate sensor (integrated with pressure sensor on 6L80; standalone on 8L90) - Install OEM sensor (GM part #24227868 for 6L80; #84436485 for 8L90) - Torque to 8–10 ft-lbs and refill with Dexron VI fluid
• Repair Wiring Harness — - Identify damaged sections using UR800 continuity test - Splice with heat-shrink connectors rated for high temperatures - Secure harness away from moving parts and exhaust components - Apply dielectric grease to connectors to prevent corrosion
• Transmission Fluid Service — - Drain and replace fluid with Dexron VI (capacity: 5–7 quarts for pan service) - Install new filter (critical for 8L90 transmissions) - Verify level with engine running and transmission at operating temperature
• TCM Reprogramming — - Use UR800 to check for calibration updates - Update software if newer version available (2020+ models often require this) - Clear codes and perform test drive to confirm proper operation

7. Repair Costs & Safety Tips for Silverado 1500

Critical Safety Precautions

• Allow transmission to cool completely before pan removal to avoid burns.
• Disconnect battery negative terminal when working on electrical components.
• Use jack stands when raising vehicle—never rely solely on a jack.
• Verify fluid level correctly per Silverado service manual to prevent damage.
• Dispose of used transmission fluid properly (local recycling centers accept it).

8. Preventive Maintenance for Silverado 1500 P0711

Reduce P0711 risk with these transmission-focused steps:

• Change transmission fluid every 60,000 miles (45,000 miles for towing use).
• Inspect sensor wiring during fluid changes for signs of corrosion or abrasion.
• Use UR800 monthly to monitor TFT sensor values during normal operation.
• Avoid aggressive driving when transmission is cold—allow proper warm-up.
• Check fluid level quarterly (with engine running, transmission in park, at operating temp).
• Update TCM software during scheduled dealer visits (critical for 2020+ models).

9. Frequently Asked Questions

10. Summary

P0711 (Transmission Fluid Temperature Sensor Circuit Low Input) is a critical code for Chevrolet Silverado 1500 owners, indicating issues with the TFT sensor or its circuit. Common causes include sensor failure, wiring damage, low/contaminated fluid, or TCM issues. Symptoms range from harsh shifting to limp mode activation, risking transmission damage if unaddressed.

UR800’s advanced diagnostics—including live voltage monitoring, resistance testing, and TCM communication checks—enable accurate identification of root causes. Most cases resolve with sensor replacement, wiring repairs, or fluid service. Regular transmission maintenance and proactive monitoring with UR800 help prevent P0711 and extend transmission life.
