1. What is P219B in Honda Civic Type R?

P219B is an OBD-II Diagnostic Trouble Code defined as Oxygen Sensor Signal Stuck Rich (Bank 1, Sensor 1). For the Honda Civic Type R—iconic front-wheel-drive performance car with a 306HP K20C1 2.0T直喷发动机—this code targets the upstream (pre-catalytic converter) oxygen sensor: a critical component that monitors exhaust gas oxygen levels to adjust fuel injection, directly impacting power delivery (e.g., turbo boost response) and emissions compliance.

The Civic Type R’s ECM expects the upstream O2 sensor to fluctuate between 0.1–0.9V (lean to rich) as it adjusts fuel mixture. P219B triggers when the sensor stays above 0.8V (rich) for 20+ seconds—signaling the ECM is injecting too much fuel, or the sensor is faulty and misreading exhaust gas. This is widespread in 2019-2023 Civic Type R models, addressed in Honda Technical Service Bulletin (TSB) 22-086 for O2 sensor contamination and fuel injector leaks in high-performance use.

2. Common Causes in 2017-2024 Civic Type R Models

P219B in Civic Type Rs ties to K20C1 engine’s high-performance design and fuel system stress—here are MA200 V6-diagnosed cases:

• Faulty Upstream O2 Sensor (2021 Civic Type R FK8): An FK8 owner with 52,000 miles noticed reduced turbo response. MA200 V6’s O2 Sensor Voltage Test showed 0.85V steady (normal: 0.1–0.9V fluctuate). Track days caused sensor contamination (unburned fuel)—replacing with OEM #36532-5LA-A01 restored normal voltage swings.
• Fuel Injector Leak (2022 Civic Type R FL5): An FL5 owner’s P219B paired with strong fuel odor. MA200 V6’s Fuel Injector Balance Test showed Cylinder 3 injector leaking (15% over fueling). High fuel pressure (K20C1’s 3,000 psi) wore the injector seal—replacing with OEM #16450-5LA-003 fixed the leak.
• Intake Manifold Leak (2019 Civic Type R FK8): A FK8 owner’s P219B was intermittent after cold starts. MA200 V6’s Intake Vacuum Test showed 16 inHg (target: 19–21 inHg). A cracked intake gasket let unfiltered air enter, tricking the ECM into rich fueling—replacing with OEM #17105-5LA-000 resolved it.
• Carbon Buildup on Sensor (2023 Civic Type R FL5): An FL5 owner’s P219B appeared after using low-octane fuel. MA200 V6’s Sensor Inspection showed carbon deposits on the O2 sensor tip. Low-octane fuel caused incomplete combustion—cleaning the sensor with Honda-approved cleaner (#08718-0031) and switching to 93-octane fixed voltage.

3. Key Symptoms in Honda Civic Type R

P219B symptoms in Civic Type Rs focus on performance loss and fuel waste—watch for these signs, especially after track days or hard acceleration:

4. Civic Type R Engines/Trims Prone to P219B

Honda service data highlights these 2017-2024 Civic Type R configurations with highest P219B rates (all K20C1 2.0T):

5. Diagnostic Steps with ICARZONE MA200 V6

Diagnose P219B in your Civic Type R accurately with MA200 V6’s Honda-specific tools—follow these steps (engine warm to 195°F first):

Case Example: A 2021 Civic Type R FK8 failed Step 2 (0.87V steady) and Step 3 (3,300 psi fuel pressure). MA200 V6’s Component Location guided O2 sensor access (remove driver’s-side heat shield). Replacing the sensor and adjusting fuel pressure fixed P219B—verified by track test (restored 22 psi boost and 0–60 time).

6. Fixes for Civic Type R's P219B

Resolve P219B in your Civic Type R with these MA200 V6-verified fixes (match to diagnosis results):

1. Replace Upstream O2 Sensor (Bank 1 Sensor 1)

1. Confirm sensor failure via MA200 V6’s Voltage Test—let exhaust cool 45+ minutes (turbo heat = burn risk).
2. Access the sensor (Civic Type R: Remove driver’s-side exhaust manifold heat shield (10mm socket)).
3. Disconnect sensor connector (press tab) and remove with a 7/8" O2 socket (use penetrating oil for stuck threads).
4. Install OEM O2 sensor (critical: match generation):
   • FK8 (2017-2021): #36532-5LA-A01
   • FL5 (2022-2024): #36532-5LA-A02
5. Torque to 30 ft-lbs, clear codes with MA200 V6, and test drive (verify boost returns to 22 psi = success).

2. Repair Fuel Injector Leak (High-Pressure K20C1)

1. Confirm leak via MA200 V6’s Fuel Pressure Test—relieve fuel pressure (remove fuel pump fuse, start engine until it stalls).
2. Remove intake manifold (Civic Type R: 8 bolts, 10mm socket) to access injectors.
3. Disconnect injector harness and remove old injectors (press tab on connector).
4. Install OEM injectors with new seals (#16450-5LA-003) + apply fuel injector grease to O-rings.
5. Reinstall manifold, reset fuel pressure, and use MA200 V6’s Fuel Injector Relearn function to calibrate.

3. Fix Intake Manifold Leak

1. Confirm leak via MA200 V6’s Vacuum Test—remove intake manifold (Step 2 above).
2. Inspect gasket for cracks (FK8 early models: common failure point) and replace with OEM #17105-5LA-000.
3. Clean manifold mating surface with brake cleaner—remove old gasket residue.
4. Reinstall manifold (torque bolts to 18 ft-lbs in crisscross pattern) and retest vacuum with MA200 V6.

7. Repair Costs & Maintenance Tips

Civic Type R P219B repair costs vary by cause—use this table to budget (note: avoid low-octane fuel during repairs):

Maintenance Tips for Civic Type R Owners

• Track-driven FK8/FL5: Replace O2 sensor every 60,000 miles (preventive, per TSB 22-086)—OEM sensors resist contamination better than aftermarket.
• Use only 93-octane gasoline (minimum 91 octane)—low-octane fuel causes incomplete combustion, coating the O2 sensor.
• Add Honda Fuel System Cleaner (#08718-0031) to a full tank every 10,000 miles—reduces injector deposits and O2 sensor contamination.
• After track days: Let the engine idle for 5 minutes before turning it off—burns excess fuel from the exhaust, protecting the O2 sensor.
• Inspect intake manifold gasket annually (FK8 2017-2018)—replace if cracks are visible to prevent vacuum leaks and false rich signals.
• Perform MA200 V6’s O2 Sensor Health Check quarterly (before track season) to catch stuck rich signals early.

8. Preventive Maintenance for Honda Civic Type R

Avoid P219B in your Civic Type R with these Honda-recommended steps, tailored to the K20C1’s high-performance design:

• O2 Sensor & Fuel System Care:
  • Never use aftermarket O2 sensors—they lack Honda’s ECM calibration and fail in 3–6 months of performance use.
  • For track days: Install an O2 sensor heat shield (aftermarket, e.g., Mishimoto) to reduce turbo heat exposure.
  • Replace fuel filter every 80,000 miles—clogged filters cause erratic fuel pressure, leading to rich fueling.
• Intake & Turbo Care:
  • Clean the intake manifold every 50,000 miles (FK8/FL5)—use Honda Intake Cleaner (#08718-0031) to remove carbon buildup that causes leaks.
  • Inspect turbo charge pipes for cracks annually—leaks reduce boost, tricking the ECM into rich fueling.
  • Use a high-flow air filter (e.g., K&N) and clean it every 15,000 miles—prevents debris from entering the intake and damaging gaskets.
• Engine & Oil Maintenance:
  • Change engine oil every 5,000 miles (track use) or 7,500 miles (street use)—use 0W-20 full synthetic (#Honda 08798-9032) to reduce engine deposits.
  • Replace spark plugs every 60,000 miles (OEM #ILKAR8H8S)—worn plugs cause incomplete combustion, leading to O2 sensor contamination.
  • For FL5 models: Update ECM software annually (via Honda dealer) to fix tuning conflicts that cause false P219B codes.
• Driving Habits:
  • Avoid "short trips" (less than 10 miles) after track days—lets excess fuel sit in the exhaust, coating the O2 sensor.
  • Use "+R Mode" only on tracks—not public roads—reduces aggressive fueling that wears injectors and contaminates sensors.
  • Refuel at top-tier stations (e.g., Chevron, Shell)—high-quality fuel has detergents that keep injectors and sensors clean.
